Description
PERFORMANCE SPECIFICATIONS
Part Number———————- SEM-48V1800-M SEM-48V3600-M
Cell Type————————– Supercapacitor battery
Energy Storage——————- 1.8KWh | 3.6KWh
Rated Voltage——————– 48V/DC | 48V/DC
Maximum Charge Voltage—– 58.8V/DC | 58.8V/DC
Discharge Cut-off Voltage——- 39.2V/DC | 39.2V/DC
ESR/AC @1KHz 50% SOC——- <12mɏ | <20mɏ
Max. Continuous Charge Current—— 30A | 200A
Max. Continuous Discharge Current— 80A | 200A
Cut-off Current (charging)————– 4A | 4A
Absolute Peak Current 3s————— 100A 300A
Charge Temperature——————— 0˫ ~+55˫
Discharge Temperature—————– -20˫ ~+60˫
Self-discharge—————————- Rate 2% per month
Recommended Depth of Discharge—- ч 90%
Maximum Depth of Discharge——— 100%
Cooling Method————————- Natural cooling
Storage Conditions———————-20˫ ~+40˫ |25% ~ 95%RH|SOC>30%one full charge needed per two months
Monitoring Data———————— System voltage,current, temperature, SOC,SOH,cycle,cell’s voltage
COMPLIANCE INFORMATION
Certificate Options———————- EN 62133:2013, EN 55032:2015+AC:2016, EN 55035:2017 EN 61000-3-2:2014, EN 61000-3-3:2013, UN38.3
CONVENTIONAL PARAMETERS
Dimensions(WxDxH)—————— 230x180x300(mm) | 793x355x252(mm)
Weight———————————– 15.5kg | 55Kg
Operating Humidity——————- 0~90% RH Non-condensing
Environmental Protection———— IP65
