Description
| Part Number | GTEM-400V14.4K-R | |
| Energy storage | 14.4kWh | |
| Nominal Voltage | 400Vdc | |
| Maximum Charge Voltage | 453.6Vdc | |
| Discharge Cut-off Voltage | 291.6Vdc | |
| ESR/AC @1KHz 50% SOC | <200mΩ | |
| Max. Continuous Charge Current | 30A | |
| Max. Continuous Discharge Current | 30A | |
| Round Trip Efficiency*1 | 96% | |
| Projected Cycle Life ( 25℃) | 20,000 times | |
| Recommended Depth of Discharge | ≤90% | |
| Maximum Depth of Discharge | 100% | |
| Cooling Method | Natural | |
| Shell Material | Metal & ABS plastic | |
| Monitoring Data | System voltage,current, temperature,
SOC,SOH,cycle,cell’s voltage |
|
| Parallel connection optional | Up to 4sets (400V 60KWh) | |
| Communication | CAN, RS485 |
| Weight | 165kg±5kg |
| Dimensions(WxDxH) | 520x732x653(mm) |
| Mount Options | On floor |
