Description
| Part Number | GTEM-400V50K-R |
| Energy storage | 50.3kWh |
| Nominal Voltage | 400Vdc |
| Maximum Charge Voltage | 448.2Vdc |
| Discharge Cut-off Voltage | 324Vdc |
| ESR/AC @1KHz 50% SOC | <100mΩ |
| Max. Continuous Charge Current | 120A |
| Max. Continuous Discharge Current | 120A |
| Round Trip Efficiency*1 | 97.5% |
| Projected Cycle Life ( 25℃) | 10,000 times (70%EOL) |
| Recommended Depth of Discharge | ≤90% |
| Maximum Depth of Discharge | 100% |
| Cooling Method | Natural |
| Shell Material | Metal & ABS plastic |
| Monitoring Data | System voltage,current, temperature,
SOC,SOH,cycle,cell’s voltage |
| Parallel connection optional | Cannot be connected in parallel (If parallel connection is required, please inform in advance ) |
| Weight | 500kg |
| Dimensions(WxDxH) | 611x735x1487(mm) |
| Mount Options | On floor |
