| Part Number |
GTEM-48V7500-E |
| Energy storage |
7.5kWh |
| Nominal Voltage |
51.8Vdc |
| Maximum Charge Voltage |
58Vdc |
| Discharge Cut-off Voltage |
42Vdc |
| ESR/AC @1KHz 50% SOC |
<10mΩ |
| Max. Continuous Charge Current |
100A |
| Max. Continuous Discharge Current |
100A |
| Cooling Method |
Natural |
| Cells Self-discharge Rate |
2% per month |
| Projected Cycle Life ( 25℃) |
20,000 times |
| Recommended Depth of Discharge |
≤90% |
| Maximum Depth of Discharge |
100% |
| Shell Material |
Metal & ABS plastic |
| Monitoring Data |
System voltage, current, temperature, SOC, SOH, cycle, cell’s voltage |
| Series Connection |
Not allowed |
| Parallel Connection |
Up to 16 sets |
| Series-Parallel Connection |
Not allowed |
